Rehau Synego System
Redan Trend sets the latest trends in the window industry. Modern, ascetic design gives the windows a unique character. Windows from this line have universal properties allowing the use of a wide range of glass packages thanks to which we can meet high thermal insulation standards.
Technical parameters:
- DECCO profile system
- 6-chamber system with a construction depth of 81 mm
- arctic white profiles
- modern design – sharp edges give the windows a modern look
- excellent thermal insulation of profiles: Uf = 1.1 W/m2K
- 2-glazed package Ug = 1.1 W/m2K as standard
- increased safety thanks to excellent peripheral fittings
- heat transfer coefficient for a reference window with a width of 1230 mm and a height of 1480 mm Uw = 1.30 W/m2K
- possibility of obtaining Uw = 1.1 W/m2K using swisspacer V warm frames and Ug = 1.0 glass
- optimal profile assembly height providing up to 5% more light than competitive systems in this class
- profile core matched to the color of decorative foils
- all seals in black – glazing bead in gray
- possibility of using a thermal insert improving the thermal parameters of the structure
- “warm” window sill strip with a seal that facilitates the installation of window sills
Redan Termo Trend system
We present to you a new window profile system designed with geometric elegance and made of the highest quality PVC. Large chambers allow the use of reinforcements that provide exceptional stability. Our latest work is perfect for both single-family construction and large investments.
Technical parameters
- DECCO profile system
- 7-chamber system with a construction depth of 81 mm with a third central seal – MD system
- window profile thickness in the highest class A and arctic white color
- modern design – sharp edges give the windows a modern look
- excellent thermal insulation of profiles: Uf = 0.97 W/m2K
- 3-glazed package Ug = 0.5 W/m2K
- increased security thanks to excellent MACO MULTI MATIC fittings with anti-burglary catch, sash lifter and tilt lock
- heat transfer coefficient for a reference window with a width of 1230 mm and a height of 1480 mm Uw = 0.86 W/m2K
- possibility of obtaining Uw = 0.70 W/m2K when using swisspacer V warm frames and an insulating insert in the frame
- optimal profile assembly height providing 55 more light than competitive systems in this class
- profile core matched to the color of decorative foils
- all seals in black – glazing bead in gray
- The “golden line” that distinguishes REDAN windows
- possibility of using a thermal insert improving the thermal parameters of the structure
- “warm” under-sill strip with a seal facilitating the installation of window sills
Rehau Synego system
If you value a warm, comfortable interior and cost savings, and want to keep heat in your home, REDAN SYNEGO windows will be the right choice. Thanks to the new SYNEGO windows, your home will become an oasis of silence, warmth and safety. Compared to the current window standard, SYNEGO will provide up to 50% better thermal insulation, thanks to which we will significantly reduce heating bills. Other features of the Synego system include:
- up to 20 times less noise
- up to 10 times greater anti-burglary protection
- possibility of obtaining Uw = 0.66 W/m2K for the reference window using a four-glass package Ug = 0.4 W/m2K
- use of a central seal – additional improvement of thermal insulation and better rain and wind protection
- acoustic insulation: up to class Rw,p= 46 dB
- burglary resistance: up to RC3 class
- significant reduction of carbon dioxide emissions through better thermal insulation
- possibility of designing windows with large structure dimensions thanks to strengthened static properties
Technical parameters
- REHAU SYNEGO profile
- MD third seal system
- very smooth profile surface thanks to HIGH DEFINITION FINISHING technology
- 7-chamber system with a construction depth of 80 mm
- low folds 117 mm – for more light in the room
- triple glazing unit Ug=0.5 W/m2K as standard
- increased security thanks to Austrian MACO MULTI MATIC fittings with an anti-burglary catch, sash lifter and false tilt lock
- handles made with MACO SOUL technology
- heat transfer coefficient Uf=0.94 W/m2K
- heat transfer coefficient of the reference window 1230 x 1480 Uw = 0.72 W/m2K
- greater structural stiffness – in veneered windows, profiles reinforced with 2 mm thick reinforcement
- additional seal in the glazing chamber improving thermal properties
- The “golden line” that distinguishes REDAN windows
- “warm” under-sill strip with a seal, facilitating the installation of internal and external window sills
- all seals are gray
New generation VEKA SOFTLINE 82 window profiles
VEKA SOFTLINE 82 profiles are a multi-chamber system with a construction depth of 82 mm. They have the highest class A construction.
7 chambers in the frame profile and 6 in the sash profile enable a very low heat transfer coefficient to be achieved, meeting the standards applicable from 2021.
- Energy saving
With a “warm” glass with a heat transfer coefficient of Ug = 0.7 W/m²K, the entire window will have a coefficient of Uw = 0.9 W/m²K. This is an excellent parameter that allows you to use such windows not only in an energy-efficient house, but even in a passive one. - Glazing
You can choose from triple or double glazing, with glass thicknesses ranging from 24 to 52 mm. This creates the possibility of glazing the sashes
windows according to individual needs. - The highest class A
VEKA SOFTLINE 82 profiles have a multi-chamber structure of the highest class A. 7 chambers in the frame profile and 6 chambers in the leaf profile enable a very low heat transfer coefficient to be achieved. - Gaskets of excellent quality
In the standard variant, VEKA SOFTLINE 82 AD profiles have high-quality external and internal seals, which ensures their long service life. - Additional sealing
VEKA SOFTLINE 82 MD profiles use a third central seal, which reduces energy consumption and heating costs. The central seal also improves the window’s acoustic insulation. - Steel reinforcements
There is steel reinforcement in the window frame and sash, ensuring excellent window statics, durability and anti-burglary safety. - Color selection
Profiles are available in dozens of variants. White, colorful (also in the ultra-matt version), wood-like or metal-like patterns. Single- or double-sided veneered. VEKA also offers SOFTLINE 82 profiles in a version with a gray carrier laminated on both sides. Thanks to this, the window is uniform and elegantly finished. - Solid mounting
Embedding the glass to a depth of 25 mm limits water vapor condensation and makes it difficult for unwanted people to force the window.
Mass-dyed profiles
When choosing colorful window profiles, it is worth paying attention to whether they are colored in the mass or whether the carrier is white and only the external foils are colored. The difference can be seen with the window open. VEKA has introduced the Sofline 82 profile to the Polish market in a version with a gray, brown or caramel carrier, foiled on both sides. Thanks to this, the window is uniform, elegantly finished, and meets the expectations of the most demanding customers who pay attention to every detail. Mass-dyed PVC increases the aesthetics of the windows.
BluEvolution 82
- installation depth 82 mm
- glazing with packages up to 53 mm wide
- up to 5 anti-burglary points as standard
Innovative technology and the best thermal parameters are characteristic features of energy-saving construction and the BluEvolution 82 system. When choosing this system, we also offer the option of choosing products with a renovation frame.
EcoSun 70
- installation depth 70 mm
- glazing with packages up to 44 mm wide
- two anti-theft latches as standard
The system is designed based on proven design solutions. It is a response to the needs of all customers – it is stable, stiff, tight and provides very good acoustic and thermal insulation.
Gealan
- installation depth 82.5 mm
- steel enclosed in the frame as standard
- glazing with STV technology only in windows
- glazing with packages up to 54 mm wide (glazing with STV technology)
- glazing with packages up to 52 mm wide (traditional glazing)
- installation depth 35 mm
The S9000 window system is distinguished primarily by the ability to build large structures without the need to install crossbars. As standard, windows made in the S 9000 system are welded using V-Perfect technology. The STV dry glass gluing technology was also used – the glass is glued to the sash rebate. Additionally, the profiles are colored using acrylcolor technology.
